iSC series
Ultrasonic Metal Tube Sealer
Main feature
  • The sixth generation iQS operating system, multi-level password protection and hierarchical authorization
  • UTC embedded stacked series of high-end processors to achieve high-speed and extreme control
  • Excellent weld stability
  • Compact structure using welding narrow area
  • Support MES, DPS system and self-developed DataLog to cooperate with 5G application
  • Using graphic analysis for quality monitoring, supporting four brands of scanners.
Learn more

Ultrasonic Metal Tube Sealer

The iSC series developed by Dongho is a newly developed welding process product, which is used for airtight welding of copper tubes in the refrigeration circuit. The copper tubes in which the refrigerant circulates are installed in the refrigeration circuit. This application is also suitable for aluminum tubes, sealing The method is developed by Dongho technology, with stricter standard deviation and significantly higher process capability, providing stronger welding strength, modular design combined with control system, multiple welding modes and trigger modes, easy to operate, no open flame, no open flame during cutting and welding Smoke and odor will not have any adverse effects on operators. There is an automatic alarm function for defective welding products, and the degree of automation integration is high and the welding consistency is good. It is suitable for products such as refrigerators and air conditioners.

Specifications

Model:iSC

Frequency:20KHz

Power:2500W-4000W

Voltage:AC220V-380V

Motion System:Pneumatic

Operating Device:7" color touch screen

Application

The iSC series ultrasonic tube sealer can cut and seal copper and aluminium tubes for
thermostats and copper tubes for refrigeration circuits.
Tubes for refrigeration circuits Features:
Material: Copper,Aluminium
Diameter:Ф3-10mm
Wall thickness:0.3-1mm

Typical application
  • Refrigeration Technology
  • Copper tube refrigeration circuit
  • Capillary tube for thermostat
  • Aluminum tube sealing and cutting
  • Copper pipe sealing
